IMC C SERIES User Manual

© 2018 imc Test & Measurement GmbH
imc C-SERIES - Manual, Version 4 R 3 - 2018-10-19
132 Technical Specs
6.2 CS-1016-FD analog inputs
Inputs, measurement modes
Parameter
Value
Remarks
Analog inputs
16
Measurement modes
voltage measurement
current measurement
current feed sensors (IEPE/ICP)
ACC/DSUBM-I4
with DSUB-15 extension plug
ACC/DSUB-ICP4, not isolated
ACC/DSUBM-ICP2I-BNC, isolated
Sampling rate, Bandwidth, Filter, TEDS
Parameter
Value
Remarks
Sampling rate
per channel
Bandwidth
0 Hz to 6.6 kHz
0 Hz to 5 kHz
-3 dB (analog AAF 5th order)
-0.2 dB
Filter (digital)
cut-off frequency
characteristic,
order
2 Hz to 5 kHz
Butterworth, Bessel (digital)
low pass filter 8. order
Anti-aliasing filter:
Cauer 8. order with f
cutoff
= 0.4 f
s
Resolution
16 Bit
internal processing 24 Bit
TEDS
conforming to IEEE 1451.4
Class II MMI
Characteristic curve
linearization
user defined
(max. 1023 supporting points)
General
Parameter
Value typ.
min. / max.
Remarks
Overvoltage protection
± 40 V
permanent channel to chassis
Input coupling
DC
Input configuration
differential
Input impedance
20 MΩ
differential, >10 kΩ off-state
Auxiliary supply
voltage
available current
internal resistance
+5 V
0.26 A
1.0 Ω
±5%
0.2 A
<1.2 Ω
for IEPE/ICP-extension plug
independent of integrated sensor
supply, short-circuit protected power
per DSUB-plug
