IMC C SERIES User Manual

© 2018 imc Test & Measurement GmbH
imc C-SERIES - Manual, Version 4 R 3 - 2018-10-19
134 Technical Specs
6.3 CS-1208-FD analog inputs
Channels, measurement modes
Parameter
Value
Remarks
Analog inputs
8
Measurement modes
voltage measurement
current measurement
current fed sensors (IEPE/ICP)
voltage (ACC/DSUBM-U4)
shunt plug (ACC/DSUBM-I4)
with DSUB-15 extension plug:
ACC/DSUB-ICP4, not isolated
ACC/DSUBM-ICP2I-BNC, isolated
Sampling rate, Bandwidth, Filter, TEDS
Parameter
Value
Remarks
Sampling rate
£ 100 kHz
per channel
Bandwidth
0 Hz to 48 kHz
0 Hz to 30 kHz
-3 dB
-0.1 dB
Filter (digital)
cut-off frequency
characteristic
order
10 Hz to 20 kHz
Butterworth, Bessel
low pass or high pass filter: 8th order
band pass: LP 4th and HP 4th order
Anti-aliasing filter: Cauer 8.order
with f
cutoff
= 0.4 f
s
Resolution
16 Bit
internal processing 24 Bit
TEDS
conforming to IEEE 1451.4
Class II MMI
ACC/DSUBM-TEDS-xx
Characteristic curve
linearization
user defined
(max. 1023 supporting points)
General
Parameter
Value typ.
min./ max.
Remarks
Overvoltage protection
±80 V
±50 V
permanent channel to chassis
range >±10 V and device switched off
Input coupling
DC
Input configuration
differential
Input impedance
1 MΩ
20 MΩ
range: >±10 V
Auxiliary supply
voltage
available current
internal resistance
+5 V
>0.26 A
1.0 Ω
±5%
>0.2 A
<1.2 Ω
for IEPE (ICP) plug
independent of optional
sensor supply, short circuit proof
power per DSUB-plug
