IMC C SERIES User Manual

© 2018 imc Test & Measurement GmbH
imc C-SERIES - Manual, Version 4 R 3 - 2018-10-19
139CS-3008-FD
6.5 CS-4108-FD, CL-4124-FD analog inputs
Channels, measurement modes
Parameter
Value
Remarks
Channels
8
24
CS
CL
Measurement modes
voltage measurement
current measurement
thermocouple, RTD (PT100)
current fed sensors (IEPE/ICP)
voltage (ACC/DSUBM-U4)
shunt plug (ACC/DSUBM-I4)
thermo plug (ACC/DSUBM-T4)
with DSUB-15 extension plug:
ACC/DSUB-ICP4, not isolated
ACC/DSUBM-ICP2I-BNC, isolated
Sampling rate, Bandwidth, Filter, TEDS
Parameter
Value
Remarks
Sampling rate
£ 100 kHz
£ 10 kHz
per channel
at temperature measurement
Bandwidth
0 Hz to 11 kHz
0 Hz to 8 kHz
0 Hz to 1 kHz
-3 dB
-0.2 dB
-0,1 dB at temperature measurement
Filter (digital)
cut-off frequency
characteristic
type and order
2 Hz to 5 kHz
Butterworth, Bessel
low pass filter: 8th order
high pass filter: 4th order
band pass: LP 4th and HP 4th order
Anti-aliasing filter:
Cauer 8.order with f
cut-off
= 0.4 f
a
Resolution
16 Bit
internal processing 24 Bit
TEDS - Transducer
Electronic DataSheets
conforming to IEEE 1451.4
Class II MMI
ACC/DSUBM-TEDS-xx
Characteristic curve
linearization
user defined
(max. 1023 supporting points)
General
Parameter
Value typ.
min. / max.
Remarks
Isolation
galvanically isolated
channel-to-channel and against system
ground (housing, CHASSIS, PE), as well as
against common reference of all PT100
current sources and TEDS.
not isolated when using ICP connector
and PT100 mode
nominal rating
test voltage
±60 V
±300 V (10 sec.)
Overvoltage protection
± 60 V
ESD 2 kV
differential input voltage, continuous
human body model
