IMC C SERIES User Manual

© 2018 imc Test & Measurement GmbH
imc C-SERIES - Manual, Version 4 R 3 - 2018-10-19
157CAN FD Interface
6.10 Miscellaneous
6.10.1 Color Display
Parameter
Color Display
Display
5.7² TFT
Colors
65536
Resolution
320 x 240
Backlight
LED
Contrast (typ.)
600:1
Brightness (typ.)
450 cd/m
2
Connection cable
RS232, max. 2 m
Dimensions (W x H x D)
192 x 160 x 30 mm (w/o connectors)
Display area
approx. 11.5 x 8.6 cm
Weight
approx. 1 kg
Supply voltage
9 V to 32 V
DC
6 V to 50 V
DC
upon request
Power consumption
approx. 3 W with 100% back light
Temperature range
-20°C to +60°C
operating temperature
module interior temperature
Rel. humidity
80% up to 31°C,
above 31°C: linear declining to 50%, according DIN EN61010-1
Terminal connections
DSUB-9 (female) for connection to measurement device
3-pin Binder (metal) ESTO RD03 series 712, 3-pin for external current supply
Miscellaneous
membrane touch panel with 15 buttons
robust metal frame
anti-reflection coated glass pane to protect display
Description the display and the DSUB-9 pin configuration .
Included accessories
· Modem cable in the extended temperature range
· AC/DC power supply unit
· POWER plug
