IMC C SERIES User Manual

© 2018 imc Test & Measurement GmbH
imc C-SERIES - Manual, Version 4 R 3 - 2018-10-19
156 Technical Specs
6.9 CAN FD Interface
Parameter
Value
Remarks
Number of CAN-nodes
2
one galvanically isolated node per
connector
Terminal connection
2x DSUB-9
Topology
bus
Transfer protocol
configurable per software:
CAN FD (ISO Standard)
(max. 8 MBaud)
non-ISO CAN FD (Draft)
(max. 8 MBaud)
CAN High Speed
(max. 1 MBaud)
CAN Low Speed
(max. 125 KBaud)
individually for each node
current standard
according ISO 11898-1:2015
former draft (Bosch)
according ISO 11898
according ISO 11519
Operating mode
Multi Master principle
Direction of data flow
sending and receiving
Baud rate
5 kBit/s to 8 MBit/s
configurable via software; maximum is
depending on selected protocol
(FD/High/Low Speed)
Termination
120 Ω
switchable by software for each node
Isolation strength
60 V
to system ground (case, CHASSIS)
Direct access for configuration
of imc CANSAS modules
yes
via the CAN node of the device
with imc STUDIO
(CAN High Speed Mode only)
Reference
Please find here the pin configuration and in the following chapter the description of the
cabling .
175
74
