147CS-5008-FD, CL-5016-FD analog inputs
6.7 CS-7008-FD, CL-7016-FD analog inputs
Inputs, measurement modes
Parameter
Value
Remarks
Inputs
8
16
CS
CL
Measurement modes
voltage measurement
ACC/DSUBM-UNI2
current measurement
Single-ended (internal shunt) or
shunt plug ACC/DSUBM-I2
thermocouple measurement
bridge sensor
strain gauge
full, half, quarter bridge
PT100 (3- and 4-wire configuration)
current-fed sensors (IEPE/ICP)
with DSUB-15 extension plug:
ACC/DSUBM-ICP2I-BNC, isolated
Sampling rate, Bandwidth, Filter, TEDS
Parameter
Value
Remarks
Sampling rate
£ 100 kHz
per channel
Bandwidth
0 Hz to 48 kHz
0 Hz to 30 kHz
0 Hz to 10 Hz
-3 dB
-0.1 dB
-3 dB for temperature measurement
Filter (digital)
cut-off frequency
characteristic
type and order
10 Hz to 20 kHz
Butterworth, Bessel
low pass or high pass filter: 8th order
band pass: LP 4th and HP 4th order
Anti-aliasing filter: Cauer 8th order
with f
cutoff
= 0.4 f
s
Resolution
16 Bit
internal processing 24 Bit
TEDS Transducer
Electronic Data Sheets
conforming to IEEE 1451.4
Class II MMI
ACC/DSUBM-TEDS-xxx
Characteristic curve
linearization
user defined
(max. 1023 supporting points)
