Sensor supply
Parameter
Value
Remarks
Configuration options
5 selectable settings
The sensor supply module always has 5
selectable voltage settings.
default selection: +5 V to +24 V
Output voltage
Voltage
(+1 V)
(+2.5 V)
+5.0 V
+10 V
+12 V
+15 V
+24 V
( ± 15 V)
Current
580 mA
580 mA
580 mA
300 mA
250 mA
200 mA
120 mA
190 mA
Power
0.6 W
1.5 W
2.9 W
3.0 W
3.0 W
3.0 W
2.9 W
3.0 W
set jointly for all eight channels
optional, special order: +12 V or +15 V can
be replaced by +2.5 V
possible ranges with 2.5 V option:
+2.5 V, +5.0 V, +10 V, +12 V, +24 V
optional, special order: +15 V can be
replaced by ± 15 V. This eliminates the
internal current- and quarter bridge
measurement.
Isolation
non isolated
output to case (CHASSIS)
Short-circuit protection
unlimited duration
to output voltage reference ground: "-VB"
Accuracy of output voltage
<0.25% (typ.) / <0.5% (max.)
<0.9% (max.)
at terminals, no load
at 25°C
over entire temperature range
Compensation of cable
resistances
3-line control:
SENSE line as refeed
(-VB: supply ground)
calculated compensation with bridges
Max. capacitive load
>4000 µF
>1000 µF
>300 µF
2.5 V to 10 V
12 V, 15 V
24 V
The description of the CS-5008-FD, CL-5016-FD.
