Page #137 background imageLoading...
Page #137 background image
© 2018 imc Test & Measurement GmbH
imc C-SERIES - Manual, Version 4 R 3 - 2018-10-19
137CS-1208-FD analog inputs
6.4 CS-3008-FD
Inputs, measurement modes
Parameter
Value
Remarks
Inputs
8
Measurement modes
voltage measurement
IEPE-sensor with current-fed
Sampling rate, Bandwidth, Filter, TEDS
Parameter
Value
Remarks
Sampling rate
£
100 kHz
per channel
Bandwidth
0 Hz to 48 kHz
0 Hz to 30 kHz
-3 dB
-0.1 dB
Filter (digital)
cut-off frequency
characteristic
order
10 Hz to 20 kHz
Butterworth, Bessel
low pass or high pass filter: 8th order
band pass: LP 4th and HP 4th order
Anti-aliasing filter: Cauer 8.order
with f
cutoff
= 0.4 f
s
Resolution
16 Bit
internal processing 24 Bit
TEDS
conforming to IEEE 1451.4
Class I Mixed Mode Interface
TEDS-data and analog
signal shared wire
2
Characteristic curve
linearization
user defined
(max. 1023 supporting points)
General
Parameter
Value typ.
min. / max.
Remarks
Overvoltage protection
±
50 V
continuous channel to chassis
Input coupling
AC, DC, AC with current feed
Input configuration
differential
Single-ended
software-configurable
Input impedance
range >±10 V
333 k
0.67 M
1 M
at DC-voltage resp. 50 Hz
ICP (Single-ended)
AC (differential)
DC (differential)
range
£±
10 V
908 k
1.82 M
20 M
ICP (Single-ended)
AC (differential)
DC (differential)
Filter cut-off frequency
(high pass, 3th order,-3 dB)
0.43 Hz
0.48 Hz
1.06 Hz
0.07 Hz
AC, ICP, range
£
±10 V (CRFX)
AC, ICP, range
£
±10 V (CRC, CRSL, CRPL)
AC, range >±10 V
special version CRFX/ICPU2-8-70mHz *
*
This special version is available on request. However, it should only be used when actually needed, as the settling times
are correspondingly extended (up to the minute range).
