IMC C SERIES User Manual

© 2018 imc Test & Measurement GmbH
imc C-SERIES - Manual, Version 4 R 3 - 2018-10-19
136 Technical Specs
Sensor supply module (Cx-12xx-SUPPLY)
Parameter
Value (typ. / max.)
Remarks
Configuration options
5 selectable settings
The sensor supply module always has 5
selectable voltage settings.
default selection: +5 V to +24 V
Output voltage
Voltage
(+2.5 V)
+5.0 V
+10 V
+12 V
+15 V
+24 V
( ± 15 V)
Current
580 mA
580 mA
300 mA
250 mA
200 mA
120 mA
190 mA
Netpower
1.5 W
2.9 W
3.0 W
3.0 W
3.0 W
2.9 W
3.0 W
set jointly for all eight channels
optional, special order, +12 V or 15 V can
be replaced by +2.5 V
preferred selection with 2.5 V:
+2.5 V, +5.0 V, +10 V, +12 V, +24 V
optional, special order: +15 V
can be replaced by ± 15 V
Isolation
Standard:
option, upon request:
non isolated
isolated
output to case (CHASSIS)
nominal rating: 50V, test voltage (10sec.):
300 V, not available with option ±15 V.
Short-circuit protection
unlimited duration
to output voltage reference ground
Accuracy of output voltage
<0.25% (typ.) / <0.5% (max.)
<0.9% (max ).
at terminals, no load
25°C
over entire temperature range
Max. capacitive load
>4000 µF
>1000 µF
>300 µF
2.5 V to 10 V
12 V, 15 V
24 V
The description of the CS-1208-FD .
89
