IMC C SERIES User Manual

© 2018 imc Test & Measurement GmbH
imc C-SERIES - Manual, Version 4 R 3 - 2018-10-19
143CS-4108-FD, CL-4124-FD analog inputs
6.6 CS-5008-FD, CL-5016-FD analog inputs
Channels, measurement modes, terminal connection
Parameter
Value
Remarks
Inputs
8
16
CS
CL
Measurement modes
voltage measurement
current measurement
ACC/DSUBM-I2 shunt-plug or
Single-ended (internal shunt)
bridge sensor
ACC/DSUBM-B2
strain gauges
full, half, quarter bridge
current-fed sensors (IEPE/ICP)
with DSUB-15 extension plug:
ACC/DSUBM-ICP2I-BNC, isolated
Sampling rate, Bandwidth, Filter, TEDS
Parameter
Value
Remarks
Sampling rate
£ 100 kHz
per channel
Bandwidth
0 Hz to 5 kHz
-3 dB
Filter (digital)
cut-off frequency
characteristic
order
1 Hz to 2 kHz
Butterworth, Bessel (digital)
low pass or high pass filter 8th order
band pass, LP 4th and HP 4th order
Anti-aliasing filter: Cauer 8.order
with f
cutoff
= 0.4 f
s
Resolution
16 Bit
internal processing 24 Bit
TEDS
conforming IEEE 1451.4 Class II MMI
ACC/DSUBM-TEDS-xx
Characteristic curve
linearization
user defined
(max. 1023 supporting points)
General
Parameter
Value typ.
min. / max.
Remarks
Overvoltage protection
±40 V
permanent
Input coupling
DC
Input configuration
differential
Input impedance
20 MΩ
±1%
Auxiliary supply
voltage
available current
internal resistance
+5 V
0.26 A
1.0 Ω
±5%
0.2 A
<1.2 Ω
only with DSUB-15 variant
for IEPE/ICP extension plug
independent of integrated
sensor supply, short-circuit protected
power per DSUB-plug
