© 2018 imc Test & Measurement GmbH
imc C-SERIES - Manual, Version 4 R 3 - 2018-10-19
129General technical Specs
Maximum channel count per device
Active channels
512
active channels of the current configuration:
Total sum of analog, digital, fieldbus and virtual channels as well
as possible monitor channels
Fieldbus channels
1000
Number of defined channels (active and passive);
Currently activated channels are limited by the total number of
activated channels (512).
Process vector variables
800
The process vector is a collection of single-value variables, each
containing the latest current measured values. A process vector
variable is automatically created for each channel.
without monitor channels
with monitor channels
Channel
type
determined
by
limit
(aktive+passive)
activated
total
activated
limit
(aktive+passive)
activated
total
activated
Analog
channels
depending
device type
8..24
8..24
512
Channel
8..24
16..48
512
Monitor
8..24
Incremental
counter
standard
4
4
Channel
4
4
Monitor
4
4
Digital DI-
Ports
standard
1
1
Port
1
1
Monitor
1
1
Digital
DO/DAC-
Ports
standard
2
2
Port
2
2
Fieldbus-
channels
definable
(dbc)
1000
512
Channel
1000
512
Monitor
Virtual
channels
(OFA)
definable
(OFA)
-
512
-
-
512
DI-ports (respectively channels) have monitor-ports, DO/DAC-ports in contrary do not have monitor-ports
