IMC C SERIES User Manual

© 2018 imc Test & Measurement GmbH
imc C-SERIES - Manual, Version 4 R 3 - 2018-10-19
141CS-4108-FD, CL-4124-FD analog inputs
Current measurement with shunt plug
Parameter
Value typ.
min. / max.
Remarks
Input ranges
±40 mA / ±20 mA / ±10 mA
±5 mA / ±2 mA / ±1 mA
Shunt impedance
50 Ω
external plug ACC/DSUBM-I4
Input configuration
differential
Gain error
<0.02%
<0.05%
<0.1%
of the measured value, with 25°C
additional error of 50 Ω in plug
Gain drift
6 ppm/K ×D T
a
50 ppm/K ×D T
a
over entire temp.
range
Offset error
0.02%
<0.05%
of the measurement range
Offset drift
2.5 ppm/K ×D T
a
over entire temperature range
D T
a
=|T
a
-25°C| ambient temperature T
a
Temperature measurement - thermocouples
Parameter
Value typ.
min. / max.
Remarks
Measurement mode
R, S, B, J, T, E, K, L, N
Measurement range
-270°C to 1370°C
-270°C to 1100°C
-270°C to 500°C
type K
Resolution
0.063 K (1/16 K)
16-Bit integer
Measurement error
< ± 0,6 K
type K, range -150°C to 1200°C
type T, range -150°C to 400°C
type N, range 380°C to 1200°C
< ± 1.0 K
type K, range -200°C to -150°C
type T, range -200°C to -150°C
< ± 1.5 K
type N, range -200°C to 380°C
Temperature drift
± 0.02 K/K ×D T
a
D T
a
=|T
a
-25°C| ambient temperature T
a
Error of cold junction
compensation
< ± 0.15 K
with ACC/DSUBM-T4
Temperature drift
± 0.001 K/K ×D T
a
D T
a
=|T
a
-25°C| ambient temperature T
a
Temperature measurement – PT100
Parameter
Value
Remarks
Measurement range
-200°C to +850°C
-200°C to +250°C
Resolution
0.063 K (1/16 K)
Gain error
<±0.05%
of measured value (corresponding
resistance)
Offset error
<±0.2 K
with 4-wire configuration
Offset drift
± 0.01 K/K D T
a
D T
a
=|T
a
-25°C| ambient temperature T
a
Sensor feed
250 µA
non-isolated
