IMC C SERIES User Manual

© 2018 imc Test & Measurement GmbH
imc C-SERIES - Manual, Version 4 R 3 - 2018-10-19
151CS-7008-FD, CL-7016-FD analog inputs
Temperature measurement - PT100
Parameter
Value typ.
min. / max.
Remarks
Input range
-200°C to 850°C
-200°C to 250°C
Resolution
0.063 K (1/16 K)
Measurement error
0.25 K
0.02%
0.1 K
0.02%
4-wire measurement:
-200°C to 850°C
of reading
-200°C to 250°C
of reading
Drift
0.01 K/K ×D T
a
D T
a
=|T
a
-25°C| ambient temperature T
a
Sensor feed (PT100)
1.25 mA
Sensor supply
Parameter
Value
Remarks
Configuration options
5 selectable settings
The sensor supply module always has 5
selectable voltage settings.
default selection: +5 V to +24 V
Output voltage
Voltage
(+1 V)
(+2.5 V)
+5.0 V
+10 V
+12 V
+15 V
+24 V
( ± 15 V)
Current
580 mA
580 mA
580 mA
300 mA
250 mA
200 mA
120 mA
190 mA
Power
0.6 W
1.5 W
2.9 W
3.0 W
3.0 W
3.0 W
2.9 W
3.0 W
set jointly for all eight channels
optional, special order: +12 V or +15 V can
be replaced by +2.5 V
preferred selection with 2.5 V:
+2.5 V, +5.0 V, +10 V, +12 V, +24 V
optional, special order: +15 V can be
replaced by ± 15 V. This eliminates the
internal current- and quarter bridge
measurement.
Isolation
non isolated
output to case (CHASSIS)
Short-circuit protection
unlimited duration
to output voltage reference ground: "-VB"
Accuracy of output voltage
<0.25% (typ.) / <0.5% (max.)
<0.9% (max.)
at terminals, no load
at 25°C
over entire temperature range
Compensation of cable
resistances
3-line control:
SENSE line as refeed
(-VB: supply ground)
calculated compensation with bridges
Max. capacitive load
>4000 µF
>1000 µF
>300 µF
2.5 V to 10 V
12 V, 15 V
24 V
