IMC C SERIES User Manual

© 2018 imc Test & Measurement GmbH
imc C-SERIES - Manual, Version 4 R 3 - 2018-10-19
39Measurement types
4.6.2.2.9 Full bridge with 4 active strain gauges in uniaxial direction
 N
4
K
U
U
B
IN
4N 
U
IN
U
B

1

2

3

4

1

2

3

4

1

3

2

4
The circuit consists of 4 active WSGs. Two are under compression and the others under equal tension.
The strain gauges under tension are positioned in opposite bridge arms. The sensitivity to the moment of
bending is increased. At the same time, longitudinal force, torque and temperature are compensated.
The strain is computed as:
k: gauge factor
