Lighting & Electrical 107 Section 4
IMT 5005i / 6006i - Manual # 99904387
51727502 PARTS LIST
ITEM NO. PART NO. DESCRIPTION QTY.
1. 60045031 WIRE 18GA X 4 GRN 6
2. 60119335 CONTROL HANDLE 1
3. 60111141 TRIGGER (PART OF 25) 1REF
4. 60119277 COVER 1
5. 70034306 BACK COVER 1
6. 70029119 PLACARD, SERIAL NUMBER 1
7. 77044196 CORD GRIP, LOCTITE 1
8. 77044621 PIN 23
9. 70394447 DECAL-DGR RC ELECTRO SM 1
10. 70394142 DECAL-TELESCOPIC REMOTE 95 1
11. 77044969 SWITCH, ROTARY ELEC (PART OF 25) 1REF
12. 72066340 POP RIVET 2
13. 72531833 BUSHING, RED STL 3/4 X 1/2 1
14. 72061009 SHT MTL SCR #6X3/4 PH 8
15. 77040051 TERM-SPRSPD #8 16-14GA 16
17. 77040372 TOGGLE SWITCH SPDT 4
18. 77040373 TOGGLE SWITCH SPST 1
20. 77044579 CONNECTOR 1
21. 89044100 CABLE 18GA 24WIRE 30 FT
23. 77044695 TERMINAL, FSLPON 1
24. 70733518 BRACKET, TRIGGER (PART OF 25) 1REF
25. 51716499 TRIGGER ASSEMBLY (INCL 3,11,24,26,28-29) 1
26. 72601346 SCR-MACH #8-32 PAN HEAD (PART OF 25) 4REF
27. 70395995 DECAL-CAUTION RC HANDLE ELEC PWR UNIT 1
28. 70143223 SPRING, TENSION (PART OF 25) 1REF
29 72061000 SCR-SHT METAL #6X1/2 PH (PART OF 25) 1REF
30. 70145495 HEAT SHRINK 0.33 FT
NEW 20080407
NOTE:
Kit # 51717816, Tethered Cable - 30 Feet, includes items 8, 15 (qty 24), 20, 21, and 30. Order 51717816 to replace
the Cable Assembly.
