IMT 5005i Parts & Specifications

 13 Crane Reference
IMT 5005i / 6006i - Manual # 99904387
5005i & 6006i (12V) Recommended Spare Parts List
5005i 6006i (12V)
51721395 LOWER CYLINDER
QTY.
51721396 LOWER CYLINDER
QTY
9D161823 SEAL KIT 1 9D161823 SEAL KIT 1
6ID40143 PISTON 1 6ID40143 PISTON 1
6HD40022 HEAD 1 6HD40022 HEAD 1
73054999 VALVE-CBAL 73054999 VALVE-CBAL 1
77041786 SWITCH-PRESS 2750 PSI 77041786 SWITCH-PRESS 2750 PSI 1
51721386 EXTENSION CYLINDER 51721386 EXTENSION CYLINDER
51744143 SEAL KIT 1 51744143 SEAL KIT 1
6HD25015 HEAD 1 6HD25015 HEAD 1
60127830 PISTON 1 60127830 PISTON 1
73054999 VALVE-CBAL SUN01 CBBC-LHN 1 73054999 VALVE 1
99904334 BASE & MAST ASSEMBLY 99904454 BASE & MAST ASSEMBLY
60118032
CABLE CONNECTOR
MODIFICATION
1 60118032
CABLE CONNECTOR
MODIFICATION
1
72060173 CAP SCR .62-11X 3.75 HH 18 72060173 CAP SCREW .62-11X 3.75 HH 18
73051513 MOTOR-HYD 1 73051513 MOTOR-HYDRAULIC 1
76039295 GASKET-GEAR 1 76039295 GASKET-GEAR 1
77441336
SWITCH- 225A CONTACTOR (12
OR 24V)
1 77441336 SWITCH- 275A CONTACTOR 1
77441281 CABLE CONNECTOR-FEMALE 1 77441281 CABLE CONNECTOR-FEMALE 1
77441285
TERMINAL RING, INSULATED 3/8
STUD
77441285
TERM RING INSULATED 3/8
STUD
1
72060178
CAP SCREW .62-11X 4.00
HEX HEAD GRADE 8 ZINC
15
73734304 VALVE BANK (12V) 73734304 VALVE BANK (12V)
73540327 COIL (VALVE BANK) (12V) 3 77040327 COIL (VALVE BANK) 6
73540326
VALVE ASSEMBLY (VALVE &
COIL) (12V)
6 73540326
VALVE ASSEMBLY (VALVE &
COIL)
3
73734375 VALVE BANK (24V) 73734735 VALVE BANK (24V)
77040527 COIL (VALVE BANK) (24V) 3 77040527 COIL (24V) 6
73540336
VALVE ASSEMBLY (VALVE &
COIL) (24V)
6 73540326 SOLENOID VALVE (24V) 3
73511282 POWER UNIT (12V) 73511282 12V POWER UNIT (EFF.10/11/12)
77043065 MOTOR (12V) 1 77043065 MOTOR (12V) 1
73511307 PUMP 1 73511307 PUMP 1
73540517 RELIEF VALVE ASSEMBLY 1 73540517 RELIEF VALVE ASSEMBLY 1
74399495 RESERVOIR 1 74399495 RESERVOIR 1
70734788 BREATHER - CAP 1 70734788 BREATHER - CAP 1
73734791 TUBE - SUCTION 1 73734791 TUBE - SUCTION 1
70734792 STRAINER 1 70734792 STRAINER 1
73511282 POWER UNIT (24V) 73511308 24V POWER UNIT
77043065 MOTOR (24V) 1 77043066 MOTOR (24V) 1
73511307 PUMP 1 73511307 PUMP 1
73540517 RELIEF VALVE ASSEMBLY 1 73540517 RELIEF VALVE ASSEMBLY 1
74399495 RESERVOIR 1 74399495 RESERVOIR 1
70734788 BREATHER CAP 1 70734788 BREATHER - CAP 1

IMT 5005i Specifications

General

Brand	IMT
Model	5005i
Category	Construction Equipment
Language	English
