6 Section - 2
IMT 5005i / 6006i - Manual # 99904387
5005i - Load Capacity Chart
BY
CAPACITY CHART -
IMT 5005i CRANE
7-3-08
IOWA MOLD TOOLING CO., INC
BOX 189, GARNER, IA 50438
TEL: 641-923-3711 FAX: 641-923-2424
TECH PUBS GENERATED DRAWING
DR AWN B Y
AP P R OVE D BY
DAT E
DAT E
S CALE
T ITL E
S IZ E DW G NO
PAT
A
F U L L
S H T OF
1 1
NOTES:
MATL: .OO5“ VELVET FINISH LEXAN
ADHESIVE: 3M 468 HI-PERFORMANCE APPLIED AFTER SCREENING
SIZE: 6”W x 8.5"H
COLORS: BLACK ON WHITE BACKGROUND, AS SHOWN
VENDOR: CREATIVE SCREEN PRINT (CRE10) OR EQUIV.
70397492
IOWA MOLD TOOLING CO., INC.
BOX 189, GARNER, IA 50438-0189
TEL: 641-923-3711 FAX: 641-923-2424
70397492
5005i CAPACITY CHART
15°
30°
45°
60°
75°
18'
5.5 m
15'
4.6 m
12'
3.6 m
9'
2.7 m
6'
1.8 m
3'
0.9 m
0
(Base)
24'
7.3 m
21'
6.4 m
18'
5.5 m
15'
4.6 m
12'
3.6 m
9'
2.7 m
6'
1.8 m
3'
0.9 m
21'
6.4 m
5000
2268
5000
2268
4625
2098
5000
2268
3870
1755
2780
1260
4850
2200
3000
1360
2125
965
4170
1890
2550
1155
1775
805
3630
1645
2190
995
1520
690
3040
1380
1825
830
1260
570
WIRE ROPE DATA:
DIAMETER; 0.31, NON-ROTATION RESISTANT, MINIMUM BREAKING LOAD; 9160,
MAXIMUM SINGLE LINE LOAD; 2617 lb (1187 kg).
DISTANCE IN FEET/METERS / LOAD IN POUNDS/KG. WEIGHT OF LOAD HANDLING
DEVICES ARE PART OF THE LOAD LIFTED AND MUST BE DEDUCTED FROM THE CAPACITY.
DESCRIPTIONECN/CNREV
REVISIONS
DATE
A 277 ADDED WIRE ROPE INFORMATION
PER ASME B30 5-1.1.3
12-15-15 BKS
Maximum one-part line
capacity is 3000 lbs
(1360 kg). For greater
loads use two-part
line.
XXXX lbs
XXXX kg
B 277-1 Added LB/KG ledger 5-31-16 BKS
