5 Section - 2
IMT 5005i / 6006i - Manual # 99904387
5005i 6006i(12V)
WINCH SPECIFICATIONS
Winch Pull Line
3000 lb
(1361 kg)
—
Pull Line Speed Without Load
37 ft/min
(11.2 m/min)
—
First Wrap Line Speed —
11.5 ft/min
(3.5 m/min)
Third Wrap Line Speed —
14 ft/min
(4.3 m/min)
Rope Diameter
5/16” (
8 mm)
3/8”
(9.6 mm)
Wire Rope Length
80’
(24.3 m)
Cable Nominal Strength
10,540 lb
(4,780 kg)
15,100 lb
(6,850 kg)
PERFORMANCE CHARACTERISTICS - 5005I & 6006i(12V)
SPECIFICATIONS SPEED
Rotation 360º (Continuous) 48 seconds
Lower Boom Elevation -5º to +75º 30 seconds (raise); 38 (lower)
Extension Cylinder 72” (1.8 m) 30 seconds (out); 35 (in)
CHASSIS REQUIREMENTS - 5005i & 6006i(12V)
GVWR 18,000 lb (8165 kg) (Minimum)
ELECTRICAL REQUIREMENTS - 5005i & 6006i(12V)
System Voltage 12 Volts
Battery
Minimum of 2 identical batteries in parallel
750 CCA MIN per battery.
Batteries must be fully charged prior to use.
Alternator 200 Amperes MINIMUM
Engine
Running at idle speed.
Elevated RPM required if additional high amperage draw systems will be in use
while crane is being operated.
Duty Cycle
Duty cycle and absolute continuous on-time according to the crane user
manual.
Winch is not operated simultaneously with any other function.
