IMT 5005i / 6006i - Manual # 99904387
5005i & 6006i(12V) Crane Installation (99904394)
In addition to meeting the chassis requirements noted in the Technical Data section of this manual, make sure
load. Install the crane only on an IMT designed and approved truck body. The body must be designed to sustain
the forces imposed by the crane when lifting the full rated load. Install the body on the chassis before installing the
crane. Refer to the following table for parts referenced in the following crane installation drawings.
ITEM NO. PART NO. DESCRIPTION KIT NO. QTY.
1. 51721572
KIT-ELECTRICAL CRANE BODY INSTALLATION (FOR
DUAL UNDERHOOD BATTERY)
1
2. 91721647 KIT-HRDW 3203I/4004I ELEC CRANE BODY INSTL 1
3. 91721751 KIT-HRDW 5005I ELEC CRANE BODY INSTL 1
4. 51725112 KIT-ELECTRIC CRANE BODY INSTALLATION 1
5. 51725572
KIT-ELECTRIC CRANE BODY INSTALLATION (FOR
SINGLE UNDERHOOD BATTERY)
1
6. 99904317 DWG-CRANE & WINCH ASM 3203I REF
7. 60251272 BRKT-SWITCH 300 AMP ELEC CRANE 1, 4, & 5 1
8. 70734331 SWITCH-300A KEYED BATTERY DISCONNECT 1, 4, & 5 1
9. 72042097 LEVEL INDICATOR LEVEL 1, 4, & 5 1
10. 77040209 TERM-RING NI .38 STUD 1 WIRE 1 & 4 1
11. 77040529 TERM-RING NI .31 STUD 1-2 WIRE 1 & 4 3
11. 77040529 TERM-RING NI .31 STUD 1-2 WIRE 5 9
12. 77441116 FUSEHOLDER-HIGH AMP2 BOLT WITH COVER 1 1
12. 77441116 FUSEHOLDER-HIGH AMP2 BOLT WITH COVER 5 2
13. 77441219 FUSE-AMG-225 AMP 1 & 4 1
13. 77441219 FUSE-AMG-225 AMP 5 2
14. 89044276 CABLE-#1 WELDING PRESTOL 1 & 5 35 FT
15. 89392333 TUBE-HEAT SHRINK AMP 603328-20 1, 4, & 5 .50 FT
16. 72060207 CAP SCR .75-10X 3.00 HH GR8 Z 2 4
17. 72601621 CAP SCR 1.00- 8X 3.00 HH GR8 Z 3 4
18. 72601862 NUT .75-10 HEX GR8 YZ NYLOCK 2 4
19. 72062375 NUT 1.00- 8 HEX GR8 YZ NYLOCK 3 4
20. 72063116 WASHER .75 N FLAT H ASTMF436Z 2 8
21. 72063066 WASHER 1.00 FLAT HI STR 3 8
22. 72060002 CAP SCR .25-20X .75 HH GR5 Z 2 & 3 4
23. 72060634 SCR-MACH #10-24X .50 RDH 2 & 3 4
24. 72062000 NUT .25-20 HEX 2 & 3 4
25. 72062106 NUT 10-24 HEX NYLOCK 2 & 3 4
26. 72063001 WASHER .25 FLAT 2 & 3 8
27. 77441396 WIRE-2 GA GXL RED 4 35 FT
28. 77040009 TERM-RING NI .38 STUD 2 WIRE 4 1
29. 77041774 STUD-BULKHEAD PASS THRU 3/8” BLACK 1
REV. G
1. Use a lifting device capable of lifting the weight of the crane as indicated in the Technical Data section of
this manual. Attach fabric slings to the crane lower boom, centered approximately 18 inches (46 cm) from the
mast hinge. Make certain the crane is well balanced on the slings by slowly lifting approximately 6” (15 cm)
To Next Page
