IMT 5005i - 5005 I & 6006 I Geometric Configuration

 8 Section - 2
IMT 5005i / 6006i - Manual # 99904387
5005i & 6006i(12V) GeometricConguration
5'-10"
(1.77 m)
4'-3"
(1.30 m)
2'-9"
(83.8 cm)
1'-7" (48.2 cm)
10'-0" (3.05 m)
16'-0" (4.88 m)
22'-0" (6.71 m)
23'-1"
(7
.03 m)
17'-3"
(5.30 m)
11'-10"
(3.60 m)
