IMT 5005i Parts & Specifications

 4 Section - 2
IMT 5005i / 6006i - Manual # 99904387
5005i & 6006i(12V)TechnicalData-GeneralSpecications
5005i 6006i(12V)
CRANE RATING (crane rating (ft-lb)
is the rated load (lb) multiplied by the
respective distance (ft) from centerline of
rotation with all extensions retracted and
lower boom in horizontal position.)
30,000 ft-lb at 10’-0”
(4.1 tm at 3.0 m)
38,000 ft-lb at 11’-0”
(5.3 tm at 3.3 m)
Max. Horizontal Reach (From Centerline
Of Rotation)
22’-0”
(6.7 m)
Hydraulic Extension (1)
72”
(183 cm)
Manual Extension (1)
72”
(183 cm)
Lifting Height (From Base of Crane to
Centerline of Sheave)
23’-6”
(7.2 m)
Crane Weight (1H1m) 1440 lb
(653 kg)
1450 lb
(660 kg)
Crane Storage Height 37”
(94 cm)
Mounting Space Required (Crane Base) 18” x 18”
(45.7 cm x 45.7 cm)
Hydraulic System Operating Pressure 2500 PSI
(172 Bar)
Maximum Hydraulic Flow 2.6 gpm
(9.84 L/min)
Oil Reservoir Capacity 1.5 gallons
(5.7 L)
Oil Type ISO VG32, Low Pour, Anti-Wear Hydraulic Oil
CENTER OF GRAVITY
Horizontal from Centerline of Rotation
(Booms Retracted)
33”
(84 cm)
Horizontal from Centerline of Rotation
(Booms Extended)
65.5”
(166 cm)
Vertical from Bottom of Crane Base 18”
(45.7 cm)
Tie-Down Bolt Pattern (On Center)
14.75” x 14.75”
(37.5 cm x 37.5 cm)
Rotation Torque 4000 ft-lb
CYLINDER SPECIFICATIONS
Lower Boom Cylinder
4.0" bore;
21.43" stroke
(10 cm bore)
(54.4 cm stroke)
4.5” bore
21.43” stroke
(11.4 cm bore)
(183 cm stroke)
Extension Boom Cylinder
2.5” bore;
72” stroke

IMT 5005i Specifications

General

Brand	IMT
Model	5005i
Category	Construction Equipment
Language	English
