IMT 5005i Parts & Specifications

 14 Crane Reference
IMT 5005i / 6006i - Manual # 99904387
5005i 6006i (12V)
73734791 TUBE-SUCTION 1 73734791 TUBE - SUCTION 1
70734792 STRAINER 1 70734792 STRAINER 1
73511308 24V POWER UNIT QTY
77043066 MOTOR (24V) 1
73511307 PUMP 1
73540517 RELIEF VALVE ASSEMBLY 1
74399495 RESERVOIR 1
70734788 BREATHER - CAP 1
73734791 TUBE - SUCTION 1
70734792 STRAINER 1
99904335 BOOM ASSEMBLY
QTY.
99904335 BOOM ASSEMBLY
QTY
60030380 WEAR PAD- EXT CYLINDER 6006I 1 60030380
WEAR PAD- EXT CYLINDER
6006I
1
60030339
WEAR PAD-RND 2.00 DIA X .60 DIA
X 1.00 LG
6 60030339
WEAR PAD-ROUND 2.00 DIA X
.60 DIA X 1.00 LG
6
60030340
WEAR PAD-BLOCK 4.50 X 4.50 X
.44
2 60030340
WEAR PAD-BLOCK 4.50 X 4.50
X .44
2
60030341
WEAR PAD-BLOCK 4.50 X 3.50 X
.44
2 60030341
WEAR PAD-BLOCK 4.50 X 3.50
X .44
2
60133062
WEAR PAD-RND 1.00 DIA X .62 DIA
X .81L
2 60133062
WEAR PAD-ROUND 1.00 DIA X
.62 DIA X .81L
2
60132302 STOP SCREW 3/8-24 X .50 2 60132302 STOP SCREW 3/8-24 X .50 2
70144211 PIN- .75X 6.50LG WORKSAVER 70144211
PIN- .75X 6.50 LONG
1
72661514 PIN-LOCK W/HANDLE .875 X 4.25 72661514
PIN-LOCK W/HANDLE .875 X
4.25
1
60030134 SHEAVE- 8.00 NYLATRON GSM 60030134 SHEAVE- 8.00 NYLATRON GSM 2
99904336 CRANE & WINCH ASSEMBLY QTY 99904456 CRANE & WINCH ASSEMBLY QTY
51720302
CORD REEL ASM- 10 FT
(THROUGH 06/01/13)
1 51720302 CORD REEL ASM (THRU 6-1-13) 1
51725225
CORD REEL ASM- 10 FT
(EFFECTIVE 06/01/13)
1 51725225 CORD REEL ASM (EFF. 6-1-13) 1
70580198 WIRE ROPE ASM-.31 X 80’ 1 70580198 WIRE ROPE ASM 1
71413196
SPRING-.105WIRE 0.75OD 2.875
LG
1 71413196
SPRING-.105WIRE 0.75OD
2.875 LG
1
72601798 WASHER-LOCK 12MM 4 72601798 WASHER-LOCK 12MM 4
72601935 CAP SCR M12-1.75X 40 SH PLAIN 4 72601935
CAP SCR M12-1.75X 40 SH
PLAIN
4
72601938 BOLT-EYE # 8-32X 1.125 1 72601938 BOLT-EYE # 8-32X 1.125 1
77041459 SWITCH-LIMIT ZE-N-2S 1 77041459 SWITCH-LIMIT 1
77441096 CONNECTOR- .50 STR RLF .25-.38 1 77441096
CONNECTOR- .50 STR RLF
.25-.38
1
77041802
CONTACTOR-WINCH 12V
(THROUGH 05/13/13)
1 77041802
CONTACTOR-WINCH 12V
(THROUGH 05/13/13)
1
77041936
CONTACTOR-WINCH 12V
(EFFECTIVE 05/13/13)
1 77041936
CONTACTOR-WINCH 12V
(EFFECTIVE 05/13/13)
1
71570923 WINCH (12V) QTY 71570923 WINCH (12V) QTY
77041801 CONTACTOR (12V OR 24V) 1 77041802
CONTACTOR (THROUGH
05/13/13)
1
77744175 BRUSH KIT 1 77744174 BRUSH KIT 1
77566638 BRAKE ASSEMBLY 1 77566637 BRAKE ASSEMBLY 1
71570933 WINCH (24V) 71570933 WINCH (24V)
