General Information 115 Section 5
IMT 5005i / 6006i - Manual # 99904387
5005I (99904470) PARTS LIST
DECAL PLACEMENT (IF NOT SHOWN ON CRANE)
ITEM NO. PLACEMENT
15, 21, 23, 24,
28, 29
AT OR NEAR REMOTE HANDE STORAGE POINT
16. 2 ON REAR STABILIZERS
19. AT OR NEAR DRIVELINE
18, 20. ON SIDES AND REAR OF CARRIER VEHICLE
37, 38 . ON FRONT OF CARRIER VEHICLE
32 ON CRANE POWER CABLE CONNECTION AT VEHICLE BATTERY
ITEM NO. PART NO. DESCRIPTION KIT NO.
QTY IN
KIT
QTY ON
CRANE
1. 95719347 DECAL KIT - TELE COMMON 1
2. 95719348 DECAL KIT - BODY COMMON 1
3. 95721548 DECAL KIT - 5005I SPECIFIC 1
4. 70391612 DECAL-GREASE WEEKLY (LEFT) 1 9 0
5. 70391613 DECAL-GREASE WEEKLY (RIGHT) 1 6 0
6. 70392399 DECAL-LUBRICATE WORM 1 1 1
7. 70392524 DECAL-ROTATE CRANE WHILE GREAS 1 1 1
8. 70394166 DECAL-INSTR FOR MNL OPERATION 1 1 0
9. 70394443 DECAL-DANGER FREEFALLING BOOMS 1 1 1
10. 70395090 DECAL-GREASE WORM DR BRNGS 1 1 1
11. 70395324 DECAL-ASME/ANSI B30.5-TELESCOP 1 1 1
12. 70395670 DECAL-CAUTION DOWN HAUL WT 1 2 2
13. 71391522 DECAL-ANGLE INDICATOR RH 1 1 0
14. 71391523 DECAL-ANGLE INDICATOR LH 1 1 0
15. 70392213 DECAL-CAUTION DONT WASH/WAX 1 1 1
16. 70392864 DECAL-WARNING STAB STAND CLEAR 2 4 2
17. 70391598 DECAL-WARNING, MAN STAB 2 2 0
18. 70392868 DECAL-DANGER CR LOADLINE (TRK) 2 4 3
19. 70392891 DECAL-DANGER DRIVELINE 2 1 1
20. 70394445 DECAL-DANGER ELEC HZD LG TELES 2 4 3
21. 70396613 DECAL-CRANE SAFETY & OPER 2 1 1
22. 70394189 DECAL-MOBILOIL RESERVOIR 2 1 1
23. 71039134 DECAL-CAUTION OIL LEVEL 2 1 1
24. 70392982 DECAL-SERVICE & REPAIR 2 1 1
25. 71394081 DECAL-LOAD BLOCK RATING 3.0TON 3 2 2
26. 70392887 DECAL-DIAMOND IMT 5X10 3 2 2
27. 70397150 DECAL-5005I ID 3 2 2
28. 70397492 DECAL-CAPACITY CHART 5005I 3 2 2
29. 70397334 DECAL-WARNING, ELEC CR O 3 1 1
30. 71397351 DECAL-REMOTE PENDANT STORAG 3 1 1
31. 70397404 DECAL-DANGER, UNPLUG CRANL 3 1 1
32. 70397405 DECAL-CRANE POWER DISCONNECT 3 1 1
35. 70397404 DECAL-DANGER, UNPLUG CRANE 3 2 2
36. 70397405 DECAL-CRANE POWER DISCONNECT 3 1 1
REV. C
