IMT 5005i Parts & Specifications

Parts 35 Section 4
IMT 5005i / 6006i - Manual # 99904387
99904454 - MAST ASSEMBLY PARTS LIST
ITEM NO. PART NO. DESCRIPTION KIT NO. QTY.
1. 51721422 KIT-HRDW BASE & MAST 5005I 1
2. 91722221 KIT- 5005I ELECTRICAL INSTALLATION 1
3. 51721707 KIT-HYD 5005I 1
5. 52725224 WLDMT- BASE 5005I-6006I 1
6. 52722162 MAST WELDMENT-5005I/6006I 1
9. 60132385 SPACER- POWER UNIT 1
10. 70580194 CLAMP-I” CONDUIT HANGER W/BOLT 2
11. 71056632 GEAR-TRNTBL BRG 17.60” DIA 1
12. 60132856 BRKT-GREASE HOSE MNTG 4004I 1
13. 73051513 MOTOR-HYD 158-1083-001 1
14. 73734304 VALVE BANK-3 SEC SERIES 3GPM @ 500PSI 1
17. 76039295 GASKET-GEA19 008-10056-1 1
18. 70034382 CAP-GREASE PRO20 GC-RED 1 3
19. 72053301 COUPLING-GLV .12 SCH 40 1 1
20. 72053508 ZERK-NPT .12 1 1
22. 72060002 CAP SCR .25-20X .75 HH GR5 Z 1 7
23. 72060001 CAP SCR .25-20X .62 HH GR5 Z 5
24. 72060051 CAP SCR .38-16X 2.25 HH GR5 Z 1 2
26. 72060147 CAP SCR .62-11X 1.00 HH GR5 Z 1 2
27. 72060173 CAP SCR .62-11X 3.75 HH GR8 Z 1 18
28. 72060178 CAP SCR .62-11X 4.00 HH GR8 Z 1 15
29. 72062104 NUT .25-20 HEX NYLOCK 1 2
30. 72062207 NUT 8-32 HEX NYLOCK 1 4
31. 72063001 WASHER .25 FLAT 1 8
33. 72063049 WASHER .25 LOCK 1 10
34. 72063051 WASHER .38 LOCK 1 3
35. 72063053 WASHER .50 LOCK 1 3
36. 72063055 WASHER .62 LOCK 1 2
37. 72063119 WASHER .62 FLAT ASTM F436 1 31
38. 72063216 WASHER .62 N FLAT-CUT 3816 1 2
44. 72601949 CAP SCR .50-13X 1.25 SH ZC 1 2
45. 51721944 CABLE ASM- 1GA-3/8RNGX SWVL MX 60.00LG 2 1
47. 51722218 CABLE ASM- 1GA-3/8RNGX SWVL FX 13.50LG 2 1
49. 77441332 CABLE ASM- 1GA-1/4RNGX 3/8RNGX 46.50LG BLK 2 1
50. 51395121 HOSE-AA .13 X 13.50 (2-2) 100R17 3 1
52. 60132301 BRKT-VLV MNT 1
53. 73511282 POWER UNIT- 2.54CC 12VDC 1
54. 60141131 PLATE-ELEC ROTATOR BRKT BOTTOM 1
55. 60141130 PLATE- ELEC ROTATOR BRKT TOP 6006I 1
REV. L
NOTE:
APPLY BLACK “MOLUB-ALLOY 936 SF HEAVY” GEAR GREASE TO TURNTABLE GEAR.

IMT 5005i Specifications

General

Brand	IMT
Model	5005i
Category	Construction Equipment
Language	English
