IMT 5005i Parts & Specifications

Parts 37 Section 4
IMT 5005i / 6006i - Manual # 99904387
CONTACTOR ASSEMBLY PARTS LIST (99904454)
ITEM NO. PART NO. DESCRIPTION KIT NO. QTY.
1. 51721422 KIT-HRDW BASE & MAST 5005I 1
2. 91722221 KIT- 5005I ELECTRICAL INSTALLATION 1
3. 51721707 KIT-HYD 5005I 1
4. 51721396 CYL- 4.50B X 2.25R X 21.43S 33.45 CC C 1
7. 60141134 PIN-TYPE NN 1.50X 9.25 1
8. 60132610 SHROUD- TURNTABLE GEAR 5005I 1
15. 60133635 CONTACT JUNCTION 1
16. 72062002 NUT .38-16 HEX 1 1
18. 70034382 CAP-GREASE PRO20 GC-RED 1 3
23. 72060001 CAP SCR .25-20X .62 HH GR5 Z 5
25. 72060091 CAP SCR .50-13X 1.00 HH GR5 Z 1 1
30. 72062207 NUT 8-32 HEX NYLOCK 1 4
31. 72063001 WASHER .25 FLAT 1 8
33. 72063049 WASHER .25 LOCK 1 10
34. 72063051 WASHER .38 LOCK 1 3
35. 72063053 WASHER .50 LOCK 1 3
39. 72063271 WASHER # 8 W FLAT ANSI B27.2Z 1 4
41. 72602009 SCR-MACH # 8-32X 1.25 BTNHD SS 1 3
42. 72601941 SCR-MACH .25-20X .38 BTNHD ZC 1 1
43. 72602010 SCR-MACH # 8-32X 1.50 BTNHD SS 1 1
46. 77441336 SWITCH- 275A CONTACTOR (SSC42-275) 2 1
48. 77441312 CABLE ASM-10GA-#10RNGX 1/4RNGX 6.00LG 2 1
51. 72060044 CAP SCR .38-16X .75 HH GR5 Z 1 2
56. 71415015 KEEPER-PIN .50 1
REV. L
WARNING
DO NOT CONNECT ELECTRICAL POWER
TO CRANE UNTIL ALL CONNECTIONS HAVE
BEEN TESTED. SEVER INJURY COULD
RESULT. ATTACH ELECTRICAL WIRES
AND GROUNDS TO COMPONENTS BEFORE
CONNECTING TO MAST.

IMT 5005i Specifications

General

Brand	IMT
Model	5005i
Category	Construction Equipment
Language	English
