IMT 5005i Parts & Specifications

Parts 41 Section 4
IMT 5005i / 6006i - Manual # 99904387
51721267 PARTS LIST
ITEM NO. PART NO. DESCRIPTION KIT NO. QTY.
1. 9D161823 SEAL KIT-IMT 4.00B 2.25R 1.44S 1
2. 52721397 ROD ASM-2.25 DIA X 31.08 LG 1.44 S 1.50 1
3. 52721398 CASE ASM-4.00 BORE X 30.77 LG 1
4. 6HD40022 HEAD-4.00 BORE X 2.25 ROD (DUCTILE IRON) 2
5. 6ID40143 PISTON-4.00 BORE X 1.44 STGR (DUCT IRON) 2
6. 60125920 STOP TUBE - 2.25 ROD X .78 LONG 1
7. 60125699 PIN - LOCK TUBE 0.19 OD X 0.065 WALL 1 1
8. 60138275 STOP TUBE-2.25 ROD X 0.25 LONG 1 1
9. 7Q072153 O-RING - 3.5 X 3.69 0.09 70 1 1
10. 7Q072342 O RING 3.62X 4.00X .19 70 1 1
11. 7Q10P342 BACK-UP RING 3.62 BORE 4 O.D. 0.07 THK 1 1
12. 7R14P022 ROD WIPER-TYPE D 2.25 ROD 1 1
13. 7R546022 U-CUP LOADED 2.25X2.75X.38 “B 1 1
14. 7T2N4040 WEAR RING - PISTON 4.00 O.D. X .50 W 1 1
15. 7T2NX625 WEAR RING-ROD 2.25 IDX0.75 1 1
16. 7T61N143 LOCK RING-NYLON 1.43 1 1
17. 7T66P040 PISTON SEAL DYNAMIC 4.00” 1 1
18. 73054999 VALVE-CBAL SUN01 CBBC-LHN 3 1
REV. C
CYLINDER DATA
 12.57 SQ IN X 1.17 GAL  93 LBS
    8.59 SQ IN X 0.80GAL  11.65 %
 Ø4.50 OD X Ø4.00B X 28.53LG  3000 PSI
 Ø2.25 X 31.20LG  2500 PSI
 Ø1.44 X 2.62LG
 710 -740 PSI
 400 FT-LB
 21.43  30-35 FT-LB
 –  –
