Parts 45 Section 4
IMT 5005i / 6006i - Manual # 99904387
51721396 PARTS LIST
ITEM NO. PARTNO. DESCRIPTION KIT NO QTY.
1. 9D181823 SEAL KIT-4.50B 2.25R 1.44S 1
2. 52721397 ROD ASM-2.25 DIA X 31.08 LG 1.44 S 1.50 1
3. 52721399 CASE ASM- 4.50 BORE X 30.89 LG 1
4. 6HD45022 HEAD-4.50 BORE X 2.25 ROD (DUCTILE IRON) 1
5. 6ID45143 PISTON-4.50 BORE X 1.44 STGR (DUCT IRON) 1
6. 60125920 STOP TUBE - 2.25 ROD X .78 LONG 1
7. 60125699 PIN - LOCK TUBE 0.19 OD X 0.065 WALL 1
8. 60138275 STOP TUBE-2.25 ROD X 0.25 LONG 1 1
9. 7Q072155 O RING 4.00X 4.19X .09 70 1 1
10. 7Q072346 O RING 4.12X 4.50X .19 70 1 1
11. 7Q10P346 BACKUP RING-4.12 ID X 4.50 OD 1 1
12. 7R14P022 ROD WIPER-TYPE D 2.25 ROD 1 1
13. 7R546022 U-CUP LOADED 2.25X2.75X.38 “B 1 1
14. 7T2N4045 WEAR RING - PISTON 4.50 O.D. X .50 W 1 2
15. 7T2NX625 WEAR RING-ROD 2.25 IDX0.75 1 2
16. 7T61N143 LOCK RING-NYLON 1.43 1 1
17. 7T66P045 PISTON SEAL-DYNAMIC 4.50IN 1 1
18. 73054999 VALVE-CBAL SUN01 CBBC-LHN 1
19. 77041786 SWITCH-PRESS 2750 PSI NC 42IN LEAD 1
20. 51721396A CYL-4.5/2.2 21.43S 33.52CC C 1
REV. C
51721396 CYLINDER DATA
CASE ø5.13” O.D. X ø4.5” BORE X 30.89” LENGTH
ROD ø2.25” X 29.83” LONG
STROKE 21.43”
DRY WEIGHT 112.87 LB
TEST PRESSURE 3000 PSI
OPERATING PRESSURE 2500 PSI
TORQUE VALUES
CARTRIDGE TORQUE - 30-35 FT-LB
NOTES:
1. TO REDUCE DOWNTIME, REPLACE ALL COMPONENTS OF THE SEAL KIT WHENEVER THE
CYLINDER IS DISASSEMBLED.
2. APPLY “NEVER-SEEZ” REGULAR GRADE ANTI-SEIZE AND LUBRICATING COMPOUND TO THREADS
ON CYLINDER HEAD ONLY. KEEP AWAY FROM ALL SEALS.
3. APPLY “LUBRIPLATE” NO. 630-2 MEDIUM HEAVY, MULTI-PURPOSE LUBRICANT, TO ALL PISTON, HEAD
GLAND, AND HOLDING VALVE SEALS, NYLON LOCK RING, CAST IRON PISTON RINGS, AND ROD
STINGER THREADS.
4. ITEM #8, STOP TUBE, REPLACES 6A025022 WAFER LOCK. USE STOP TUBE INSTEAD OF WAFER
LOCK WHEN RESEALING CYLINDER.
