IMT 5005i Parts & Specifications

Parts 47 Section 4
IMT 5005i / 6006i - Manual # 99904387
99904335 PARTS LIST
ITEM NO. PART NO. DESCRIPTION KIT # QTY
1. 51721423 KIT-HRDW BOOM 5005I 1
2. 51721386 CYL-2.5/1.5 72.00S 7.37CC C 1
3. 52725221 LOWER BOOM WLDMNT - 5005I-6006I 1
4. 52721359 WLDMT- EXTENSION 1ST STAGE 5005I 1
5. 52721474 WLDMT- EXTENSION 1ST STAGE 5005I 1
6. 52721360 WLDMT- 2ND STAGE EXTENSION 5005I 1
7. 60133939 PIN-TYPE M 1.50X 6.00 1
8. 60030380 WEAR PAD- EXT CYLINDER 6006I 1
9. 60030339 WEAR PAD-RND 0.19X 2.00X .60X .81 6
10. 60030340 WEAR PAD-RC 0.19X 4.50X 4.50 2
11. 60030341 WEAR PAD-RC 0.19X 4.50X 3.50 2
12. 60133062 WEAR PAD-RND 0.19X 1.00X .62X .81 STL 2
13. 60132302 STOP SCREW 3/8-24 X .50 2
14. 60105544 PLATE-ANGLE PLASTIC 2
15. 72063273 WASHER .52ID X 2.00OD X 10GA 2
18. 70144211 PIN- .75X 6.50LG WORKSAVER 1
19. 72066145 HAIR PIN .19 DIA .63-1.00 SHAFT (PART OF 70144211) REF 2
20. 70034382 CAP-GREASE PRO20 GC-RED 1 1
21. 72053507 ZERK-STR THD .25-28 1 1
22. 72060013 CAP SCR .25-20X 3.25 HH GR5 Z 1 2
23. 72060092 CAP SCR .50-13X 1.25 HH GR5 Z 1 2
24. 72060928 CAP SCR .50-13X 2.25 HH GR5 Z 1 1
25. 72062103 NUT .38-16 HEX NYLOCK 1 2
26. 72062104 NUT .25-20 HEX NYLOCK 1 2
27. 72063001 WASHER .25 FLAT 1 4
28. 72063003 WASHER .38 FLAT 1 2
29. 72063005 WASHER .50 FLAT 1 5
30. 72063053 WASHER .50 LOCK 1 3
31. 72063051 WASHER .38 LOCK 1 2
32. 70144209 PIN- .75X 4.50 LG WS80-WS100 1
REV. E

IMT 5005i Specifications

General

Brand	IMT
Model	5005i
Category	Construction Equipment
Language	English
