IMT 5005i Parts & Specifications

Parts 51 Section 4
IMT 5005i / 6006i - Manual # 99904387
99904336 PARTS LIST
ITEM NO. PART NO. DESCRIPTION KIT NO. QTY
1 99904334 MAST ASM-5005I REF
2 99904335 BOOM ASM 5005I-6006I REF
3 51721424 KIT-HRDW CRANE & WINCH 6006I 1
4 51727065 CORD REEL ASM - 10.5’ - W/PACKARD CONNECTOR 1
8 52725226 WLDMT-ATB TRIP MECHANISM 1
10 60122263 PLATE-SINGLE SHEAVE 3820 1
18 71570923 WINCH-DC3000 12VDC 1
19 77041936 CONTACTOR-WINCH 12V DC3000 (COMES WITH WINCH) 18 1
20 72034485 CLAMP-PLASTIC 1/4” CABLE 4
21 72661543 PIN-QUICK 316-10QP 1
23 77441096 CONNECTOR- .50 STR RLF .25-.38 1
25 70034382 CAP-GREASE PRO20 GC-RED 3 3
26 71413196 SPRING-.105WIRE 0.75OD 2.875 LG 3 1
27 72053508 ZERK-NPT .12 3 3
28 72060000 CAP SCR .25-20X .50 HH GR5 Z 3 10
30 72060075 CAP SCR .44-14X 5.50 HH GR5 Z 3 1
32 72062093 NUT # 8-32 HEX ZINC 3 1
33 72062105 NUT .44-14 HEX NYLOCK 3 1
34 72062106 NUT 10-24 HEX NYLOCK 3 4
35 72062207 NUT 8-32 HEX NYLOCK 3 1
36 72063001 WASHER .25 FLAT 3 12
37 72063004 WASHER .44 FLAT 3 2
39 72063049 WASHER .25 LOCK 3 11
41 72063271 WASHER # 8 W FLAT ANSI B27.2Z 3 4
43 72601798 WASHER-LOCK 12MM 3 4
44 72601935 CAP SCR M12-1.75X 40 SH PLAIN 3 4
50 72602011 SCR-MACH # 8-32X .62 BTNHD ZC 3 6
51 72063239 WASHER # 8 LOCK 3 2
52 71413880 COVER W/O SOCKET 1
53 60144651 BRKT- CORD REEL MNT 1
54 52725217 WLDMT-WINCH CONTACTOR BRKT 1
REV. T
