IMT 5005i Parts & Specifications

Parts 53 Section 4
IMT 5005i / 6006i - Manual # 99904387
99904336-2 PARTS LIST
ITEM NO. PART NO. DESCRIPTION KIT NO. QTY
1 99904334 MAST ASM-5005I REF
2 99904335 BOOM ASM 5005I-6006I REF
3 51721424 KIT-HRDW CRANE & WINCH 6006I 1
6 60141135 PIN-TYPE NN 1.50X 9.75 1
7 60141134 PIN-TYPE NN 1.50X 9.25 1
9 52722163 COVER-VALVE BANK 5005I/6006I 1
11 60134104 COVER-CONTACTOR (5005I-6006I) 1
24 77441282 GROUND STRAP- 12IN 1
28 72060000 CAP SCR .25-20X .50 HH GR5 Z 3 10
31 72060091 CAP SCR .50-13X 1.00 HH GR5 Z 3 2
35 72062207 NUT 8-32 HEX NYLOCK 3 1
36 72063001 WASHER .25 FLAT 3 12
39 72063049 WASHER .25 LOCK 3 11
40 72063053 WASHER .50 LOCK 3 2
46 72601941 SCR-MACH .25-20X .38 BTNHD ZC 3 2
55 71415015 KEEPER-PIN .50 2
REV. T
NOTE:
1. Use anti-seez on pins.
2. All electrical grounds must be free of paint, grease, and oil.
3. If required use (72063036) machny bushings between mast and boom when installing pin, 52721425.

IMT 5005i Specifications

General

Brand	IMT
Model	5005i
Category	Construction Equipment
Language	English
