IMT 5005i Parts & Specifications

Parts 57 Section 4
IMT 5005i / 6006i - Manual # 99904387
99904456 PARTS LIST
ITEM NO. PART NO. DESCRIPTION KIT NO. QTY.
1. 99904454 DWG-BASE & MAST ASM 6006I REF
2. 99904335 BOOM ASM 5005I-6006I REF
3. 51721424 KIT-HRDW CRANE & WINCH 6006I 1
4. 51727065 CORD REEL ASM - 10.5’ - W/PACKARD CONNECTOR 1
8. 52725226 WLDMT-ATB TRIP MECHANISM 1
10. 60122263 PLATE-SINGLE SHEAVE 3820 1
12. 70034381 SUPPORT-GP STAUFF LN-4190-PA 2
13. 70144209 PIN- .75X 4.50 LG WS80-WS100 1
15. 70149793 COLLAR-SHAFT 2 PIECE 11/16 IN 1
18. 71570923 WINCH-DC3000 12VDC 1
19. 77041936 CONTACTOR-WINCH 12V DC3000 (COMES WITH WINCH) 18 1
20. 72034485 CLAMP-PLASTIC 1/4” CABLE 4
21. 72661543 PIN-QUICK 316-10QP 1
23. 77441096 CONNECTOR- .50 STR RLF .25-.38 1
25. 70034382 CAP-GREASE PRO20 GC-RED 3 3
26. 71413196 SPRING-.105WIRE 0.75OD 2.875 LG 3 1
27. 72053508 ZERK-NPT .12 3 3
28. 72060000 CAP SCR .25-20X .50 HH GR5 Z 3 10
29. 72060007 CAP SCR .25-20X 1.75 HH GR5 Z 3 2
30. 72060075 CAP SCR .44-14X 5.50 HH GR5 Z 3 1
32. 72062093 NUT # 8-32 HEX ZINC 3 1
33. 72062105 NUT .44-14 HEX NYLOCK 3 1
34. 72062106 NUT 10-24 HEX NYLOCK 3 4
35. 72062207 NUT 8-32 HEX NYLOCK 3 1
36. 72063001 WASHER .25 FLAT 3 14
38. 72063049 WASHER .25 LOCK 3 11
40. 72063271 WASHER # 8 W FLAT ANSI B27.2Z 3 4
41. 72601798 WASHER-LOCK 12MM 3 4
42. 72601935 CAP SCR M12-1.75X 40 SH ZC 3 4
48. 72602011 SCR-MACH # 8-32X .62 BTNHD ZC 3 6
49. 72063239 WASHER # 8 LOCK 3 2
51. 71413880 COVER W/O SOCKET 1
52. 60144651 BRKT- CORD REEL MNT 1
53. 52725217 WLDMT-WINCH CONTACTOR BRKT 1
REV. T CN616-1

IMT 5005i Specifications

General

Brand	IMT
Model	5005i
Category	Construction Equipment
Language	English
