Parts 73 Section 4
IMT 5005i / 6006i - Manual # 99904387
73511282 & 73511308 PARTS LIST
ITEM NO. PART NO. DESCRIPTION QT Y.
1. BASE ASSY,M3504,AP100,SPEC WALL 1
2. PUMP,AP100,2.5,PBP,NO COVER,CW 1
3. COVER,REAR,AP100 309,.375 NPT 1
4. O-RING,SHAPED,UP100&UP110 1
5. PIN,DOWEL,5X7 MM,AP100 4
6. O-RING,SHAPED,REAR COVER,AP100 1
7. SHAFT,INTERMEDIATE,AP100,DC 1
8. SCREW,SHC,M8X75,GRADE 8.8,ZINC 4
9. TUBE,SUCT,90,H/MT,M-3 00,3/8NPT 1
10. 70734792 FILTER,SCREEN M-SERIES SUCT. 1
11. 77043065 MOTOR,DC,12V,4.5”,1 TERM,LONG 1
12. 74399495 RESV,PLASTIC,6.7X6.7X13,H/MT 1
13. 70734788 PLUG,RESV,BREATHER-FILL,3/4-14 1
14. CLAMP,HOSE,WORM GEAR,RSV,M-SER 1
15. PLUG,CAP,NYLON,PUSH-IN,MOTOR 2
16. VALVE ASSY,R/V,1001 PSI AND UP 1
REV. AC
NOTE:
IOWA MOLD TOOLING CO., INC.
TECHNICAL SUPPORT TEAM
TELEPHONE: 800-554-4421
To Next Page
