Parts 75 Section 4
IMT 5005i / 6006i - Manual # 99904387
73511282-1 & 73511308-1 PARTS LIST
ITEM NO. PART NO. DESCRIPTION QT Y.
1. P ASSY,W.BASE,M-3504,AP100,2.53 1
2. SHAFT,INTERMEDIATE,AP100,DC 1
3. SEAL,SHAFT,OIL,12 X 22 X 7,NBR 1
4. 73734791 TUBE,SUCT,90,H/MT,M-3 00,3/8NPT 1
5. 70734792 FILTER,SCREEN M-SERIES SUCT. 1
6. 77043065 MOTOR,DC,12V,4.5”,1 TERM,LONG 1
7. 74399495 RESV,PLASTIC,6.7X6.7X13,H/MT 1
8. 70734788 PLUG,RESV,BREATHER-FILL,3/4-14 1
9. CLAMP,HOSE,WORM GEAR,RSV,M-SER 1
10. PLUG,CAP,NYLON,PUSH-IN,MOTOR 2
11. BA LL ,1/4 DIA . 1
12. SPRING,RELIEF M-SER.1001PSI&UP 1
13. SEAL,WASH,SCREW,NUT,OIL 1
14. WASHER,FLAT,25/64”,(PLATED) 1
15. NUT,HEX,JAM,3/8-16UNC-2BX9/16 1
16. SCREW,SET,3/8-16 X 1,STUB PT 1
17. VALVE ASSY,R/V,1001 PSI AND UP 1
REV. AC
NOTE:
IOWA MOLD TOOLING CO., INC.
TECHNICAL SUPPORT TEAM
TELEPHONE: 800-554-4421
