IMT 5005i Parts & Specifications

Parts 79 Section 4
IMT 5005i / 6006i - Manual # 99904387
99904438-1 PARTS LIST
ITEM NO. PART NO. DESCRIPTION KIT NO. QTY.
1. 99904336 CRANE ASM 5005I REF
2. 51721707 KIT-HYD 50051 1
3. 51399460 HOSE-FZ .25 X 15.50 (4-4) 100R17 2 1
4. 51397336 HOSE-FI .25 X 12.50 (4-4) 100R17 2 1
5. 51395874 HOSE-FJ .25 X 26.00 (4-4) 100R17 2 2
6. 51397480 HOSE-FF .25 X 27.50 (4-4) 100R17 2 2
7. 51396413 HOSE-FF .25 X 22.00 (4-4) 100R17 2 1
8. 51395422 HOSE-FF .25 X 24.00 (4-4) 100R17 2 1
9. 72053758 ELBOW-M STR/90/M JIC 4 4 2 2
10. 72532351 ADPTR-M STR/M JIC 4 4 2 7
11. 72532699 ELBOW-M STR/90/M JIC 6 4 2 1
12. 72533567 ELBOW-M STR/90/M JIC XLG 4 4 2 1
13. 72534567 ELBOW-M STR/90/M JIC XLG 6 4 2 2
14. 72533589 ADPTR-M STR/M JIC 10 4 2 2
15. 72533052 ADPTR-M STR/F STR 8 6 2 2
16. 72532522 PLUG-STR HEX HD STL .44 2
17. 73540325 VALVE-PROP FLOW CNTRL 12V ELEC CRANE 1
18. 91721626 KIT-HYD 50051 PROP 18 1
19. 51395663 HOSE-FJ .25 X 14.00 (4-4) 100R17 18 1
20. 51397434 HOSE-FZ .25 X 16.00 (4-4) 100R17 18 1
21. 51397452 HOSE-FI .25 X 11.50 (4-4) 100R17 18 1
22. 72053758 ELBOW-M STR/90/M JIC 4 4 18 1
23. 72532351 ADPTR-M STR/M JIC 4 4 18 1
24. 72532981 TEE-SWVL NUT RUN JIC 4 18 1
25. 72534477 ADPTR-M STR/M JIC 4 4 XLG 18 1
31. 72534714 TEE-STL JIC/STR/JIC 4 6 4 BRANCH 2 1
REV J
NOTE:
1. WHEN CONVERTING TO PROPORTIONAL HYDRAULIC SYSTEM ALL EXISTING HOSES ARE USED
EXCEPT 51397335 (ITEM #3).
2. CRANES WITHOUT EXTENSION CYLINDER USE PLUGS (72532522) TO BLOCK HYDRAULIC PORTS
B1 & A1 ON THE VALVE BLOCK.

IMT 5005i Specifications

General

Brand	IMT
Model	5005i
Category	Construction Equipment
Language	English
