Chapter 4 Parts 99
NOTES:
1 TO REDUCE DOWNTIME, REPLACE ALL COMPONENTS OF THE SEAL KIT WHENEVER THE CYLINDER IS
DISASSEMBLED.
71411797 CYLINDER DATA
EXTENDED 1.23 IN², 0.22 GAL
RETRACTED 0.79 IN², 0.14 GAL
CASE 1.25 BORE X ø1.63
ROD ø 0.750
DRY WEIGHT 19.7 LB
TEST PRESSURE 3000 PSI
OPERATING PRESSURE 2500 PSI
PORTS SAE #4 O-RING BOSS (7/16-20 UNF-2B)
CYLINDER TUBE BURST PRESSURE 20,000 PSI
TORQUE TORQUE LOCKNUT (#6) WITH THREADLOCK
COMPOUND TO 35-40 FT-LB
71411797 PARTS LIST
ITEM PART # DESCRIPTION QUANTITY
1. 71411933 CASE WELDMENT 1
2. 71411934 ROD WELDMENT 1
3. 71411935 HEAD GLAND 1
4. 71411936 PISTON 1
5. -REF- LOCKNUT 1-14 UNS 1
6. 94396794 SEAL KIT 1
NEW 20051010
