Chapter 4 Parts 39
71056608 PARTS LIST (PARTS SHOWN ON DRAWING 99903804)
18. 71412288 RING, GREASE 1
19. 70055310 BEARING, ROLL CONE 1
20. 70055311 BEARING, ROLL CUP 1
21. 70055312 BEARING, ROLL CONE 1
22. 71056614 GEAR, WORM 1
23. 71056615 PINION, OUTPUT 1
24. 71412289 SPACER, WASHER 1
25. 71412290 HOUSING 1
26. 71412291 COVER 1
27. 76029615 SHIM, WORM 0.010 BROWN 2
28. 76029616 SHIM, WORM 0.0075 CLEAR 2
29. 76029617 SHIM, WORM 0.005 BLUE 3
30. 76029618 SHIM, WORM 0.020 YELLOW 2
32. 76396848 O-RING 1
33. 71412292 CAP, GEAR 1
34. 71412293 CAP, WORM 1
35. 71412294 SCREW, 6-32X3/8" HWHTR 8
36. 76029610 SHIM, GEAR 0.0075 NAT ALUMINUM 4
37. 76029611 SHIM, GEAR 0.005 BLUE ALUMINUM 4
38. 76029612 SHIM, GEAR 0.003 GREEN ALUMINUM 4
39. 71412295 WORM, GROUND 1
40. 76029613 SHIM, COVER 0.005 BLUE ALUMINUM 3
41. 76029614 SHIM, COVER 0.020 YELLOW ALUMINUM 2
42. 71412296 MTR ADAPTER 1
43. 76396849 SEAL, FACE 1
REF 70734049 SHIM KIT (INCL. 27-30,35-38,40,41) 1
REF 94396846 SEAL KIT (INCL. 10,32,43) 1
