IMT 6025 User Manual

54 Model 5525-6025-6625 Parts & Specifications Manual Part # 99903688
2
42
30
59
14
55
13
33
33
12,41,45,46(2)
32,45,
52
12,41,45,46(2)
42,44
42,44
30,37,50
30,37,50
30,37,50
ADJUST TENSION
TO ALLOW 1"
OF TRAVEL
32,45,52
31,36
31,36
40,46
41,45
41,45
DO NOT OVERTIGHTEN.
MUST BE FREE TO PIVOT.
38,45
38,45,58
39,46
43,45,52
43,45,52
MOUNTING
HARDWARE
INCLUDED
WITH SWITCH
(USE O-RINGS,
SCREWS
& #6 NYLOC
HEX NUT)
2.0"
0.5"
72"
6" TYP
6"
2.0"
0.5"
72"
6" TYP
6"
START WITH
RED SEGMEN
T
BOOM-1ST STAGE EXT WELDMENT
99903756 PARTS LIST
ITEM PART # DESCRIPTION QUANTITY
1. 51719591 HARDWARE KIT- BOOM (INCL 31-34,36-58) 1
2. 51713168 CORD REEL ASM-W/PACKARD CONN 1
3. 52718005 TUBE WELDMENT- ANTI TWO BLOCK 1
4. 52718672 BOOM-1st STAGE EXT WLDMT 1
5. 52718673 BOOM-2nd STAGE EXT WLDMT 1
6. 52719124 PIN 1
7. 52719371 PIN 1
8. 52719746 BOOM-LOWER WLDMT 1
