Chapter 4 Parts 65
71410928 PARTS LIST
ITEM PART # DESCRIPTION QUANTITY
1. 001EE0006 HYDRAULIC LINE, EXT CYLINDER 2
2. 71410930 CYLINDER, 2.7/1.7 78.00 S 1
3. 71410931 CYLINDER, 2.5/1.7 72.00 S 1
4. 103MG0006 CLEVIS PIN 1
5. 106EA0006 NUT, #6 FLARELESS TUBE 4
6. 106EB0007 FERRULE, #6 FLARELESS TUBE 4
7. 108BL0002 LOCK NUT, 1.25-12 UNF 1
8. 108LZ0002 CLIP, HITCH PIN 2
9. 108NZ0005 CLAMP, HOSE 6
REV. B 20060111
NOTE:
The stroke on extension cylinder 71410931, the top cylinder in the 71410928 cylinder assembly, was shortened by 6"
effective 6-15-2007.
