Chapter 4 Parts 69
CRANE & WINCH ASSEMBLY PARTS LIST (99903693)
ITEM PART # DESCRIPTION QUANTITY
1. 41719388 BASE & MAST ASY 6025 (Worm Drive) 1
2. 41718669 BOOM ASY 5525, 6025, 6625 1
3. 51718759 HARDWARE KIT-CRANE ASSEMBLY (INCL. 4-14) 1
4. 72053508 ZERK-NPT .12 (PART OF #3) 1
5. 72060091 CAP SCR .50-13X 1.00 HH GR5 Z(PART OF #3) 2
6. 72062232 NUT .50-13 HEX TOPLOCKGR8Z(PART OF #3) 4
7. 72063053 WASHER .50 LOCK (PART OF #3) 2
8. 70034382 CAP-GREASE ZERK (PART OF #3) 1
10. 72066136 RETAINING RING-EXT 2.00 HD (PART OF #3) 2
11. 72060002 CAP SCR .25-20X .75 HH GR5 Z (PART OF #3) 4
12. 72063049 WASHER .25 LOCK (PART OF #3) 4
13. 72063001 WASHER .25 FLAT (PART OF #3) 4
14. 72063132 WASHER .50 FLAT ASTM F436 (PART OF # 3) 2
15. 91719121 HYDRAULIC KIT-CRANE ASY (INCL. 16-22) 1
16. 72053760 ELBOW-M STR/90/M JIC 6 6 (PART OF #15) 2
17. 72533373 UNION-BULKHEAD 37 DEG JIC .75 (PART OF #15) 2
18. 72533573 TEE-STL JIC/STR/JIC 4 4 4 (PART OF #15) 1
19. 72532359 ADPTR-M STR/M JIC 10 8 (PART OF ITEM #15) 2
20. 72534412 SWIVEL-M JIC/90/M JIC 10 10 (PART OF # 15) 1
21. 72533648 SWIVEL-M JIC/90/M JIC 8 8 (PART OF #15) 1
22. 72533024 UNION-BULKHEAD 37 DEG JIC .44 (PART OF #
15)
1
23. 73733171 PIN LOCK 1X6 W/HAIR PIN 1
24. 72661514 PIN 1
25. 60128847 COVER-MAST VLV BANK 6025 1
26. 52715896 GUARD WELDMENT SNATCH BLOCK 1
27. 52718741 PIN TYPE-MM 2.00 X 12.75 (11.94) 1
28. 52718903 PIN TYPE-MM 2.00 X 9.00 (8.19) 1
29. 70570771 WINCH-PLANETARY 6000 LB LINE PULL 1
30. 71411150 CABLE WEDGE (SUPPLIED W/WINCH)
31. 70580168 WIRE ROPE ASM-.44(6X25)X100' LH LAY 1
32. 70145121 COLLAR-SHAFT 2 PIECE 7/8 in. 1
33. 70732882 HOOK-SWVL POS LOCK BBRG 5.9TON 1
34. 71073035 HOOK-SWVL L-322 AN 5.0T W/LATCH 1
REV. F 20050726
