Chapter 4 Parts 71
2 INSTALL ITEM #33, PIN, THROUGH THE BOOM SIDE PLATE AND THROUGH THE WIRE ROPE CLEVIS.
3 MOUNT THE DOWNHAUL WEIGHT ON THE BOOM SIDE OF THE PLATE SHAFT.
4 REMOVE THE 90° ELBOW ON THE DRUM SIDE OF THE COUNTERBALANCE VALVE. ADD ITEM #18 AND
RECONNECT THE TUBE FROM THE COUNTERBALANCE VALVE TO THE WINCH BRAKE.
5 IF REQUIRED, USE THE 72063039 MACHY BUSHINGS BETWEEN THE MAST AND THE BOOM WHEN
INSTALLING PIN, ITEM #12.
6 THE CABLE WEDGE IS SUPPLIED WITH THE WINCH. REFER TO WINCH DRAWING FOR REPLACEMENT
PART NUMBER.
CRANE & WINCH ASSEMBLY PARTS LIST (99903695)
ITEM PART # DESCRIPTION QUANTITY
1. 41719390 BASE & MAST ASSEMBLY 1
2. 41718669 BOOM ASSEMBLY 1
3. 51718759 KIT-HARDWARE CRANE ASSEMBLY (INCL. 4-
6,10-14)
1
4. 72063132 WASHER .50 FLAT ASTM F436 (PART OF #3) 2
5. 72063053 WASHER .50 LOCK (PART OF #3) 2
6. 72060091 CAP SCR .50-13X 1.00 HH GR5 Z (PART OF #3) 2
7. 72063001 WASHER .25 FLAT 4
8. 72063049 WASHER .25 LOCK 4
9. 72060002 CAP SCR .25-20X .75 HH GR5 Z 4
10. 72062232 NUT .50-13 HEX TOP LOCK GR8 Z (PART OF #3) 4
11. 72053508 ZERK-NPT .12 (PART OF #3) 1
12. 70034382 CAP-GREASE (PART OF #3) 1
13. 72066136 RETAINING RING-EXT 2.00 HD (PART OF #3) 2
15. 91719121 HOSE KIT-CRANE ASSEMBLY (INCL. 16-23) 1
16. 72533648 SWIVEL-M JIC/90/M JIC 8 8 (PART OF #15) 1
17. 72534412 SWIVEL-M JIC/90/M JIC 10 10 (PART OF #15) 1
18. 72053760 ELBOW-M STR/90/M JIC 6 6 (PART OF #15) 2
19. 72533573 TEE-STL JIC/STR/JIC 4 4 4 (PART OF #15) 1
21. 72532359 ADPTR-M STR/M JIC 10 8 (PART OF #15) 2
22. 72533373 UNION-BULKHEAD 37 DEG JIC .75 (PART OF #15) 2
23. 72533024 UNION-BULKHEAD 37 DEG JIC .44 (PART OF #15) 1
24. 52718741 PIN 1
25. 52718903 PIN 1
26. 70570771 WINCH, 6000 # 1
27. 71411150 CABLE WEDGE (SUPPLIED WITH WINCH) 1
28. 52715896 GUARD WELDMENT 1
29. 60128847 COVER-MAST VLV BANK 1
30. 73733171 PIN LOCK 1X6 W/HAIR PIN 1
31. 70732882 HOOK-SWVL POS LOCK BBRG 5.9TON 1
32. 71073035 HOOK-SWVL W/LATCH 1
33. 72661514 PIN 2
34. 70145121 COLLAR-SHAFT 2 PIECE 7/8 in. 1
35. 70580168 WIRE ROPE ASM-.44(6X25)X100' LH LAY 1
REV. E 20050726
