Chapter 4 Parts 73
70570761 PARTS LIST
ITEM PART # DESCRIPTION QUANTITY
13. - OUTPUT PLANET GEAR 3
14. - OUTPUT PLANET GEAR SHAFT 3
15. 71411145 ROLLER BEARING 3
16. - THRUST RACE 6
17. - ROLL PIN 3
27. 71411146 SPRING 12
28. - SPRING LOCATOR 1
29. - BRAKE COUPLING 1
30. - RETAINING RING 1
31. - SPRING PLATE 1
32. - BRAKE PISTON SEAL 1 REF
33. - BRAKE PLATE SPACER 2
34. 71411147 FRICTION DISK 8
35. 71411148 STEEL DISK 9
36. - O-RING 1 REF
37. - GASKET 1 REF
38. - MOTOR ADAPTER 1
39. - BRAKE VALVE BLOCK 1
40. 71733943 COUNTERBALANCE CARTRIDGE 1
40A. 71733944 CHECK VALVE CARTRIDGE (PART OF 40) 1REF
40B. 76733945 SEAL KIT (PART OF 40) 1REF
41. - SUN GEAR 1
42. 71411149 VENT PLUG 1
43. - TUBE ASSEMBLY 1
44. - CAPSCREW (5/16-18 X 3-1/2 G5) 2
45. - ELBOW FITTING 2
46. - O-RING 2 REF
47. - CAPSCREW (5/16-18 X 1 G5) 8
48. - LOCKWASHER (5/16/) 8
49. 73511057 HYDRAULIC MOTOR (13.9 cu in) 1
50. - CAPSCREW (1/2-13 X 1-1/4 G8 Z) 2
51. - LOCKWASHER (1/2) 2
52. - RETAINING RING 1
53. 71411150 CABLE WEDGE 1
54. 94744136 SEAL KIT (INCL. 8,10,32,36,37,46) 1
REV. A 20050105
