Chapter 4 Parts 87
51719470 HANDLE ASSEMBLY WIRE FUNCTIONS
SOLID/STRIPE FUNCTION
A YEL/BLK ROT CW
B ORN/BLK EXT OUT
C BLU/BLK WINCH DN
D RED/BLK WINCH UP
E ORN/RED -
F BRN EXT IN
G BRN/RED ENG START
H BLU/RED -
J BLK/RED ENG SPEED
K BRN/BLK ROT CCW
L RED POWER
M BLU ENG STOP
N ORN LOWER DN
O BLK/ORN SOL POWER
P YEL LOWER UP
Q BRN/BLU -
R YEL/RED -
S BLK CRANE
T BLK/BLU CPRSR
U RED/BLU SIMULTANEOUS
V BLU/ORN -
W ORN/BLU -
X YEL/BLU -
- RED/RON -
51719470 PARTS LIST
ITEM PART # DESCRIPTION QUANTITY
1. 89044214 WIRE 18GA GRN 1.61 FT
2. 60119335 CONTROL HANDLE 1
3. 60111141 TRIGGER (PART OF 11) 1REF
4. 60119277 COVER 1
5. 70034306 BACK COVER 1
7. 77044196 STRAIN RELIEF 3/4 1
8. 77044621 PIN 23
9. 70394447 DECAL-DGR RC ELECTRO SM 1
10. 70396719 DECAL-CTRL 1
11. 70394183 TRIGGER ASM (INCL 3) 1
14. 72061009 SHT MTL SCR #6X3/4 PH 8
15. 77040051 TERM-SPRSPD #8 16-14GA 31
16. 77040371 TOGGLE SWITCH SPST 2
17. 77040372 TOGGLE SWITCH SPDT 4
18. 77040373 TOGGLE SWITCH SPST 2
19. 77040374 TOGGLE SWITCH SPDT 1
20. 77044579 CONNECTOR 1
21. 89044100 CABLE 18GA 24WIRE 40 FT
22. 77040147 TERM-FSLPON 1/4TAB 22-18 3
23. 77040047 TERM-MSLPON 1/4TAB 16-14 3
24. 72060602 MACH SCR #6-32X3/8 RDHD 4
25. 70145495 TUBING-HEAT SHRINK .5 FT
