IDS440 Users Manual version 4.2 Set Operation Parameters
33
Parameter 25 Serial Port 2 Mode (4 [8 data bits, no parity])
Enter the mode number from the table below to select the mode parameter in the mode
description column.
Mode Number Mode Description
1 7 data bits, no parity
2 7 data bits, even parity
3 7 data bits, odd parity
4 8 data bits, no parity
5 8 data bits, even parity
6 8 data bits, odd parity
Parameter 26 Serial Port 2 Baud Rate (1 [9600 baud])
Enter a baud number from the table below to select a baud rate from the description
column. (*HS baud rates for the 100 samples per sec version only).
Baud Number Baud Description
1 9600 Baud
2 4800 Baud
3 2400 Baud
4 1200 Baud
5 600 Baud
6 300 Baud (* HS 19.2K)
7 150 Baud (*HS 38.4K)
Parameter 27 TX2 Control / Station ID (255 [single station])
Serial Port 2 can be used for continuous transmission of scale data or as a network buss
or for single station remote control.
• Enter a 0 to enable continuous transmission of TX 2 data. The data sent is configured
in parameter 28 (TX2 Format).
• Enter a station ID (1 to 254) for multi-drop network configuration
• Enter 255 for single station remote control
