IDS440 Users Manual version 4.2
63
DT210/IDS550/IDS710/PC (Continuous Output Port)
DB 25 PIN MALE
(RS232)
TB2
Serial Com Port 2
TXD
GND
2
5
3
7
RXD
GND
DT210 / IDS550 / IDS710
DB 25 PIN MALE
(20ma Current Loop)
TB2
Serial Com Port 2
+5R
CL1 TX
4
622
CL+
CL-
DT210 / IDS550 / IDS710
8
