iNetVu Troubleshooting Guide - 1201 Flyaway
12) With one hand on the EL Actuator/Motor and the other on the Support Plate, push forward on
the Support Plate to disengage the EL Actuator. Allow the EL support plate to lean forward.
13) Disconnect all cables (Motor/Sensor, TX and RX).
14) Remove the Quick Release T-Pin attaching the elevation motor assembly to the AZ base;
ensure to hold the actuator while removing the pin.
