iNetVu Troubleshooting Guide - 1201 Flyaway
2. If the Mobile Platform physically moves but the angle doesn’t change
Possible Causes:
• Polarization Tilt Sensor (inclinometer)
• Sensor Cable
• Internal Wiring
• 7000 Controller
a. Please ensure the Flyaway Control Cable is securely connected to the 7000 Controller and
Platform. Reseat this cable at both ends and try again
b. Verify the Polarization Tilt Sensor Cable is securely connected as seen below. Try reseating this
cable. If the angle still does not update proceed to the next step.
Polarization Tilt Sensor Cable
c. Use the Sensor Circuit Diagram on the following page to confirm continuity of the Control Cable.
Set the voltmeter to beeper or continuity mode. If the Control Cable passes continuity, this will
conclude the issue is the Polarization Tilt Sensor or Internal Wiring. Please contact C-COM
Technical Support for further assistance.
Sensor Continuity Test
