iNetVu Troubleshooting Guide - 1201 Flyaway
c. If we are getting voltage from the 7000 controller, we will need to test voltage on the Control
Cable. Reconnect the Motor Cable to the controller and disconnect the Control Cable from the
base plate of the Platform. Place the volt meter leads on pins A and B of the control cable. Using
the 7000 controllers front panel, select Azimuth with HI SPEED ON and hold +. Are you getting
24VDC? If no voltage is shown, it concludes the Control Cable needs to be replaced. Contact C-
Com Technical Support for further assistance.
d. If we are getting voltage from the control cable, this indicates we may have an Azimuth Motor
or Internal Wiring issue. Please contact C-Com Technical Support for further assistance.
