IN5312/IN5314 – User’s Manual
– 5 –
18.
USB
Connect the USB CABLE from a computer
(used for presentation slide control with the projector remote)
19.
HDMI Connect the HDMI CABLE from an HDMI device
20.
AUDIO 2 Connect the AUDIO CABLE from an input device
21.
DVI-D Connect the DVI cable (not supplied) from a computer
Solid Red Normal operation
22.
READY LED
Flashing
Amber
Lamp is not ready
23.
TEMP LED Solid Red Overheating
Solid Amber Standby
Solid Blue Normal operation
24.
PWR LED
Flashing
Amber
Powering on or powering/cooling
down
47
25.
POWER button
Turns the projector on or off (main power switch must
be turned on first).
12
26.
AUDIO 1 Connect the AUDIO CABLE from an input device
27.
VGA1 Connect the RGB CABLE from a computer or a video enabled device
28.
VGA2 Connect the RGB CABLE from a computer or a video enabled device
Note:
If your video equipment has various input sources, it is recommended to connect in priority of
HDMI, component, S-Video, Composite for better picture quality.
Warning:
As a safety precaution, disconnect all power to the projector and connecting devices before making
connections.
