User’s Manual
Bottom view
ITEM LABEL DESCRIPTION SEE PAGE:
1.
Leveling/Elevator Feet
Raise and rotate the feet to change and fine tune
the angle of the projector.
16
2.
Ceiling support holes
Only use with an InFocus ceiling mount system (p/n PRJ-MNT-UNIV).
See your InFocus dealer or go to www.infocusstore.com
.
Note:
When installing, ensure that you use only UL Listed ceiling mounts.
For ceiling installations, use approved mounting hardware and M4 screws with a maximum screw
depth of 6 mm (0.23 inch).
The construction of the ceiling mount must be of a suitable shape and strength. The ceiling mount
load capacity must exceed the weight of the installed equipment, and as an additional precaution
be capable of withstanding three times the weight of the equipment over a period of 60 seconds.
– 6 –
