Ingenico AXIUM RX7000 User Manual

1.0A;
Output: 8Vdc,3A
Tmax:45℃
If additional adapters are used, please check that the poweroutput is less than 100W.
3_3_3 Terminal Connectivity
USB host High speed USB Host
in the single
connector
USB device
High speed USB Device in the single
connector
Ethernet 10/100 Base T Ethernet is available on the
RX7000. It is recommanded to use TCP
Protocol
RS232
It is a 2 wire interface on the RX7000
(Rx/Tx). It can run up to 115200bps
3_3_4 WLAN (2.4 GHz / 5 GHz)
Standard 802.11 a/b/g/n
Frequency band 2.4 GHz DTS band 2412 MHz to 2462MHz
Type of
modulation
BPSK, QPSK, 16 – QAM, 64 – QAM
Number of channels 11

Ingenico AXIUM RX7000 Specifications

General

Brand	Ingenico
Model	AXIUM RX7000
Category	Payment Terminal
Language	English
